385-5645 |
|
Seat Depth:
1 1/4"
Frame Height:
6"
Weir Perimeter (Feet):
6.2
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Round, Square/Rectangle
Catalog Number:
385-5645
Clear Opening Diameter:
22 3/8"
Frame Flange Diameter:
36"
Frame Opening Diameter:
26 3/8"
Grate Diameter:
23 3/4"
|
 |
3900-B |
PDF
|
Clear Opening Length:
22 3/4"
Clear Opening Width:
18"
Seat Depth:
2"
Frame Height:
2 3/4"
Frame Opening Length:
22 3/4"
Frame Opening Width:
18"
Frame Flange Length:
29 3/4"
Frame Flange Width:
25 3/4"
Grate Length:
25"
Grate Width:
21"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
3900-B
Bolted:
Bolted
|
|
|
3900-C |
PDF
|
Clear Opening Length:
48"
Clear Opening Width:
18"
Seat Depth:
2"
Frame Height:
2 3/4"
Frame Opening Length:
52 3/8"
Frame Opening Width:
23 1/8"
Frame Flange Length:
55"
Frame Flange Width:
25 3/4"
Grate Length:
25"
Grate Width:
21"
Weir Perimeter (Feet):
11.8
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
3900-C
Bolted:
Bolted
|
|
|
3900-D |
PDF
|
Clear Opening Length:
73 1/4"
Clear Opening Width:
18"
Seat Depth:
2"
Frame Height:
2 3/4"
Frame Opening Length:
73 1/4"
Frame Opening Width:
18"
Frame Flange Length:
77 5/8"
Frame Flange Width:
23 1/8"
Grate Length:
25"
Grate Width:
21"
Weir Perimeter (Feet):
16
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
3900-D
Bolted:
Bolted
|
 |
3910-V |
PDF
|
Seat Depth:
1 1/4"
Grate Length:
16"
Grate Width:
7.5"
Overall Scupper Length:
17 1/8"
Overall Scupper Height:
21"
Weir Perimeter (Feet):
3.1
Highest Load Rating:
H-20
Shape:
Rectangle
Outlet Type:
Plain
Grate Type:
V
Catalog Number:
3910-V
Bolted:
Bolted
Anchor Holes:
Anchor Holes
Anchor Studs:
Anchor Studs
|
 |
3918 |
PDF
|
Seat Depth:
2 1/2"
Grate Length:
30.625"
Grate Width:
15.25"
Overall Scupper Length:
38"
Overall Scupper Height:
18"
Weir Perimeter (Feet):
7.6
Highest Load Rating:
H-25
Material:
Gray Iron
Shape:
Rectangle
Outlet Type:
Plain
Grate Type:
L
Catalog Number:
3918
|
 |
3920-V |
PDF
|
Seat Depth:
2"
Grate Length:
22"
Grate Width:
14.5"
Overall Scupper Length:
30 1/2"
Overall Scupper Height:
18"
Weir Perimeter (Feet):
4.2
Outlet Diameter:
5 7/16"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Rectangle
Outlet Type:
Plain
Grate Type:
V
Catalog Number:
3920-V
Bolted:
Bolted
|
 |
3921-V1 |
PDF
|
Seat Depth:
1 1/4"
Grate Length:
22.53125"
Grate Width:
7.53125"
Overall Scupper Length:
26 1/16"
Overall Scupper Height:
13 3/4"
Weir Perimeter (Feet):
4.1
Highest Load Rating:
Contact NEI
Shape:
Rectangle
Outlet Type:
Flanged
Grate Type:
V
Catalog Number:
3921-V1
Bolted:
Bolted
Anchor Holes:
Anchor Holes
Anchor Studs:
Anchor Studs
|
 |
3923 |
|
Seat Depth:
2"
Grate Length:
22.5"
Grate Width:
22.5"
Overall Scupper Length:
26 25/32"
Overall Scupper Height:
12 3/4"
Weir Perimeter (Feet):
5.6
Highest Load Rating:
H-25
Material:
Gray Iron
Shape:
Square
Outlet Type:
Flanged
Grate Type:
V
Catalog Number:
3923
Bolted:
Bolted
Anchor Holes:
Anchor Holes
Anchor Studs:
Anchor Studs
|
 |
3924 |
PDF
|
Seat Depth:
2"
Grate Length:
35.25"
Grate Width:
15"
Overall Scupper Length:
37 5/8"
Overall Scupper Height:
20"
Weir Perimeter (Feet):
8.4
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Rectangle
Outlet Type:
Plain
Grate Type:
A
Catalog Number:
3924
Bolted:
Bolted
|
 |
3935 |
PDF
|
Seat Depth:
1 1/2"
Grate Length:
16"
Grate Width:
16"
Overall Scupper Length:
30"
Overall Scupper Height:
17"
Weir Perimeter (Feet):
5.3
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square
Outlet Type:
Plain
Grate Type:
C, V
Catalog Number:
3935
Bolted:
Bolted
|
 |
3936-A |
PDF
|
Seat Depth:
1 1/4"
Grate Length:
19"
Grate Width:
19"
Overall Scupper Length:
29 1/4"
Overall Scupper Height:
17 1/2"
Weir Perimeter (Feet):
6.5
Open Area (Sq Ft):
1"
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Square
Outlet Type:
Plain
Grate Type:
A, C
Catalog Number:
3936-A
Bolted:
Bolted
|
|
|
3945 |
PDF
|
Seat Depth:
1 1/2"
Grate Length:
23.875"
Grate Width:
14"
Overall Scupper Length:
73 7/8"
Overall Scupper Height:
8 3/8"
Weir Perimeter (Feet):
13
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Rectangle
Outlet Type:
Threaded (FNPT)
Grate Type:
Q
Catalog Number:
3945
Bolted:
Bolted
ADA Compliant Grate:
ADA Compliant Grate
|
|
|
3945-A |
PDF
|
Seat Depth:
1 1/2"
Grate Length:
23.875"
Grate Width:
14"
Overall Scupper Length:
74 1/16"
Overall Scupper Height:
13 3/8"
Weir Perimeter (Feet):
13
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Rectangle
Outlet Type:
Plain
Grate Type:
L
Catalog Number:
3945-A
Bolted:
Bolted
|
 |
3949-A |
PDF
|
Seat Depth:
2 3/8"
Grate Length:
41.75"
Grate Width:
23.75"
Overall Scupper Length:
43 1/2"
Overall Scupper Height:
21"
Weir Perimeter (Feet):
8.9
Outlet Diameter:
11 15/16"
Highest Load Rating:
H-20
Shape:
Rectangle
Outlet Type:
Plain
Grate Type:
Q
Catalog Number:
3949-A
Bolted:
Bolted
ADA Compliant Grate:
ADA Compliant Grate
|
 |
3951 |
PDF
|
Seat Depth:
1 1/2"
Grate Length:
23.875"
Grate Width:
14"
Overall Scupper Length:
57 1/2"
Overall Scupper Height:
10 3/4"
Weir Perimeter (Feet):
9
Highest Load Rating:
H-20
Shape:
Rectangle
Outlet Type:
Plain
Grate Type:
Q
Catalog Number:
3951
Bolted:
Bolted
ADA Compliant Grate:
ADA Compliant Grate
|
|
|
3956 |
PDF
|
Seat Depth:
1"
Grate Length:
27.5"
Grate Width:
27.5"
Overall Scupper Length:
29 3/8"
Overall Scupper Height:
10 1/2"
Weir Perimeter (Feet):
6.9
Highest Load Rating:
Contact NEI
Material:
Ductile Iron
Shape:
Square
Outlet Type:
Plain
Grate Type:
A, Q, S
Catalog Number:
3956
ADA Compliant Grate:
ADA Compliant Grate
|
 |
396 |
|
Seat Depth:
1 3/4"
Frame Height:
6"
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Round
Frame Type:
Flange Down
Catalog Number:
396
Clear Opening Diameter:
30"
Cover Diameter:
31 3/4"
Frame Flange Diameter:
39 1/4"
Frame Opening Diameter:
34"
Bolted:
Bolted
Gasket:
Gasket
Non-Penatrating Pick:
Non-Penatrating Pick
|
 |
398 |
|
Seat Depth:
1 3/8"
Frame Height:
8"
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Round
Frame Type:
Flange Down
Catalog Number:
398
Clear Opening Diameter:
24"
Cover Diameter:
25 3/4"
Frame Flange Diameter:
39"
Frame Opening Diameter:
32"
Bolted:
Bolted
Gasket:
Gasket
Non-Penatrating Pick:
Non-Penatrating Pick
Open Pick:
Open Pick
|
 |
398-5618 |
|
Seat Depth:
1 3/8"
Frame Height:
8"
Weir Perimeter (Feet):
6.7
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Round, Square/Rectangle
Catalog Number:
398-5618
Clear Opening Diameter:
24"
Frame Flange Diameter:
39"
Frame Opening Diameter:
32"
Grate Diameter:
25 3/4"
|
|
|
3990-C |
PDF
|
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Catalog Number:
3990-C
Trench Clear Opening:
10"
Trench Grate Width:
12"
Bolted:
Bolted
Frame Length:
24"
Trench Grate Length:
23 7/8"
ADA Compliant Grate:
ADA Compliant Grate
|
 |
4000-6349 |
PDF
|
Clear Opening Length:
30"
Clear Opening Width:
30"
Seat Depth:
1 1/2"
Frame Height:
4"
Frame Opening Length:
32"
Frame Opening Width:
32"
Frame Flange Length:
37 1/2"
Frame Flange Width:
37 1/2"
Grate Length:
31 3/4"
Grate Width:
31 3/4"
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
4000-6349
|
 |
4008-6008 |
|
Clear Opening Length:
20"
Clear Opening Width:
20"
Seat Depth:
1"
Frame Height:
8"
Frame Opening Length:
23 1/4"
Frame Opening Width:
23 1/4"
Frame Flange Length:
34"
Frame Flange Width:
34"
Grate Length:
21 3/4"
Grate Width:
21 3/4"
Weir Perimeter (Feet):
7.5
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
4008-6008
|
 |
401 |
|
Seat Depth:
1 1/8"
Frame Height:
8"
Material:
Gray Iron
Shape:
Round
Frame Type:
Flange Down
Catalog Number:
401
Clear Opening Diameter:
30"
Cover Diameter:
31 7/8"
Frame Flange Diameter:
44"
Frame Opening Diameter:
34"
|
