2370 |
- |
- |
24.125" |
6.9375" |
PDF
|
Seat Depth:
1 1/2"
Frame Height:
6.9375"
Weir Perimeter (Feet):
6.8
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Round, Square/Rectangle
Grate Type:
A, C, G
Catalog Number:
2370
Clear Opening Diameter:
24.125"
Frame Flange Diameter:
35.875"
Frame Opening Diameter:
30.28125"
Grate Diameter:
26"
Bolted:
Bolted
ADA Compliant Grate:
ADA Compliant Grate
|
 |
240-5640 |
- |
- |
20 1/4" |
6" |
|
Seat Depth:
2"
Frame Height:
6"
Weir Perimeter (Feet):
5.9
Highest Load Rating:
H-20
Material:
Gray Iron
Shape:
Round, Square/Rectangle
Catalog Number:
240-5640
Clear Opening Diameter:
20 1/4"
Frame Flange Diameter:
32 3/4"
Frame Opening Diameter:
24"
Grate Diameter:
22 3/4"
|
|
|
2433 |
23 1/2" |
23 1/2" |
- |
4" |
PDF
|
Clear Opening Length:
23 15/16"
Clear Opening Width:
21"
Seat Depth:
2"
Frame Height:
4"
Frame Opening Length:
23 15/16"
Frame Opening Width:
21"
Frame Flange Length:
29 1/4"
Frame Flange Width:
28 1/2"
Grate Length:
23 1/2"
Grate Width:
23 1/2"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2433
|
|
|
2434 |
23 1/2" |
23 1/2" |
- |
4" |
PDF
|
Clear Opening Length:
47 3/4"
Clear Opening Width:
21"
Seat Depth:
2"
Frame Height:
4"
Frame Opening Length:
47 3/4"
Frame Opening Width:
21"
Frame Flange Length:
52 11/16"
Frame Flange Width:
29 1/2"
Grate Length:
23 1/2"
Grate Width:
23 1/2"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2434
|
|
|
2440 |
29 3/4" |
17 3/4" |
- |
5" |
PDF
|
Clear Opening Length:
27 7/8"
Clear Opening Width:
15 7/8"
Seat Depth:
2 5/8"
Frame Height:
5"
Frame Opening Length:
27 7/8"
Frame Opening Width:
15 7/8"
Frame Flange Length:
38"
Frame Flange Width:
26"
Grate Length:
29 3/4"
Grate Width:
17 3/4"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2440
Bolted:
Bolted
Curb Box Available:
Curb Box Available
|
|
|
2440-A |
29 3/4" |
17 3/4" |
- |
- |
|
Seat Depth:
2 1/2"
Grate Length:
29 3/4"
Grate Width:
17 3/4"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2440-A
Curb Box Available:
Curb Box Available
|
|
|
2440-L |
29 3/4" |
17 3/4" |
- |
3 1/8" |
PDF
|
Clear Opening Length:
27 3/4"
Clear Opening Width:
15 3/4"
Seat Depth:
2 1/2"
Frame Height:
3 1/8"
Frame Opening Length:
27 3/4"
Frame Opening Width:
15 3/4"
Frame Flange Length:
32 1/8"
Frame Flange Width:
20 1/8"
Grate Length:
29 3/4"
Grate Width:
17 3/4"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2440-L
Bolted:
Bolted
Curb Box Available:
Curb Box Available
|
|
|
2440LB |
29 3/4" |
17 3/4" |
- |
- |
|
Clear Opening Length:
26 3/8"
Seat Depth:
2 1/2"
Grate Length:
29 3/4"
Grate Width:
17 3/4"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2440LB
Bolted:
Bolted
|
|
|
2441 |
29 3/4" |
17 3/4" |
- |
5" |
PDF
|
Clear Opening Length:
28"
Clear Opening Width:
15 7/8"
Seat Depth:
2 5/8"
Frame Height:
5"
Frame Opening Length:
28"
Frame Opening Width:
15 7/8"
Frame Flange Length:
38"
Frame Flange Width:
23 1/16"
Grate Length:
29 3/4"
Grate Width:
17 3/4"
Highest Load Rating:
Contact NEI
Catalog Number:
2441
Bolted:
Bolted
Curb Box Available:
Curb Box Available
|
|
|
2442 |
29 3/4" |
17 3/4" |
- |
5" |
PDF
|
Clear Opening Length:
28"
Clear Opening Width:
15 7/8"
Seat Depth:
2 5/8"
Frame Height:
5"
Frame Opening Length:
28"
Frame Opening Width:
15 7/8"
Frame Flange Length:
35 1/8"
Frame Flange Width:
23 1/16"
Grate Length:
29 3/4"
Grate Width:
17 3/4"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2442
Bolted:
Bolted
Curb Box Available:
Curb Box Available
|
|
|
2443 |
29 3/4" |
17 3/4" |
- |
5" |
PDF
|
Clear Opening Length:
28"
Clear Opening Width:
15 7/8"
Seat Depth:
2 5/8"
Frame Height:
5"
Frame Opening Length:
28"
Frame Opening Width:
15 7/8"
Frame Flange Length:
35 1/8"
Frame Flange Width:
23 1/16"
Grate Length:
29 3/4"
Grate Width:
17 3/4"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2443
Bolted:
Bolted
Curb Box Available:
Curb Box Available
|
|
|
2444 |
29 3/4" |
17 3/4" |
- |
5" |
|
Clear Opening Length:
28"
Clear Opening Width:
15 7/8"
Seat Depth:
2 5/8"
Frame Height:
5"
Frame Opening Length:
28"
Frame Opening Width:
15 7/8"
Frame Flange Length:
31 15/16"
Frame Flange Width:
23 1/16"
Grate Length:
29 3/4"
Grate Width:
17 3/4"
Highest Load Rating:
Contact NEI
Catalog Number:
2444
Bolted:
Bolted
Curb Box Available:
Curb Box Available
|
|
|
2445 |
- |
- |
- |
- |
|
Highest Load Rating:
Contact NEI
Catalog Number:
2445
Curb Box Available:
Curb Box Available
|
|
|
2446 |
- |
- |
- |
13 1/2" |
|
Frame Height:
13 1/2"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Catalog Number:
2446
Curb Box Available:
Curb Box Available
|
|
|
2467 |
- |
- |
20.09375" |
9.84375" |
|
Seat Depth:
1 1/2"
Frame Height:
9.84375"
Weir Perimeter (Feet):
5.9
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Round, Square/Rectangle
Grate Type:
C, D, E
Catalog Number:
2467
Clear Opening Diameter:
20.09375"
Frame Flange Diameter:
37.40625"
Frame Opening Diameter:
26.5625"
Grate Diameter:
23"
|
|
|
2500 |
- |
- |
22.25" |
7.46875" |
PDF
|
Seat Depth:
1 1/2"
Frame Height:
7.46875"
Weir Perimeter (Feet):
6.2
Highest Load Rating:
H-25
Material:
Gray Iron
Shape:
Round, Square/Rectangle
Grate Type:
H
Catalog Number:
2500
Clear Opening Diameter:
22.25"
Frame Flange Diameter:
34.65625"
Frame Opening Diameter:
25.78125"
Grate Diameter:
24"
Bolted:
Bolted
|
|
|
2501-A |
39 1/4" |
22 3/4" |
- |
5" |
PDF
|
Clear Opening Length:
37 1/4"
Clear Opening Width:
20 3/4"
Seat Depth:
2"
Frame Height:
5"
Frame Opening Length:
39 1/2"
Frame Opening Width:
23"
Frame Flange Length:
48"
Frame Flange Width:
31"
Grate Length:
39 1/4"
Grate Width:
22 3/4"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2501-A
|
|
|
2501-L |
39 1/4" |
22 3/8" |
- |
5" |
PDF
|
Clear Opening Length:
37 1/4"
Clear Opening Width:
20 1/2"
Seat Depth:
2"
Frame Height:
5"
Frame Opening Length:
39 5/8"
Frame Opening Width:
23"
Frame Flange Length:
48"
Frame Flange Width:
31"
Grate Length:
39 1/4"
Grate Width:
22 3/8"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2501-L
|
|
|
2502 |
39 1/4" |
22 5/8" |
- |
5" |
PDF
|
Clear Opening Length:
37 1/4"
Clear Opening Width:
20 3/4"
Seat Depth:
2"
Frame Height:
5"
Frame Opening Length:
39 1/2"
Frame Opening Width:
23"
Frame Flange Length:
48"
Frame Flange Width:
38 1/2"
Grate Length:
39 1/4"
Grate Width:
22 5/8"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2502
Curb Box Available:
Curb Box Available
|
|
|
2502-L |
39 1/4" |
22 3/8" |
- |
5" |
PDF
|
Clear Opening Length:
37 5/16"
Clear Opening Width:
20 11/16"
Seat Depth:
2"
Frame Height:
5"
Frame Opening Length:
39 1/2"
Frame Opening Width:
23"
Frame Flange Length:
48"
Frame Flange Width:
38 1/2"
Grate Length:
39 1/4"
Grate Width:
22 3/8"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2502-L
Curb Box Available:
Curb Box Available
|
|
|
2504 |
- |
- |
20 7/8" |
9" |
PDF
|
Seat Depth:
1 3/4"
Frame Height:
9"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Round, Square/Rectangle
Grate Type:
D
Catalog Number:
2504
Clear Opening Diameter:
20 7/8"
Frame Flange Diameter:
34"
Frame Opening Diameter:
24 1/2"
Grate Diameter:
22 3/4"
|
|
|
2510 |
27" |
15" |
- |
2 3/4" |
PDF
|
Clear Opening Length:
24"
Clear Opening Width:
12"
Seat Depth:
2"
Frame Height:
2 3/4"
Frame Opening Length:
24"
Frame Opening Width:
12"
Frame Flange Length:
32"
Frame Flange Width:
17 1/2"
Grate Length:
27"
Grate Width:
15"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2510
|
|
|
2512 |
27" |
15" |
- |
2 3/4" |
PDF
|
Clear Opening Length:
24"
Clear Opening Width:
12"
Seat Depth:
2"
Frame Height:
2 3/4"
Frame Opening Length:
24"
Frame Opening Width:
12"
Frame Flange Length:
36"
Frame Flange Width:
32"
Grate Length:
27"
Grate Width:
15"
Highest Load Rating:
Contact NEI
Material:
Gray Iron
Shape:
Square/Rectangle
Catalog Number:
2512
|
|
|
2540 |
- |
- |
20.5" |
6" |
|
Frame Height:
6"
Weir Perimeter (Feet):
5.9
Highest Load Rating:
H-25
Material:
Gray Iron
Shape:
Round, Square/Rectangle
Grate Type:
D
Catalog Number:
2540
Clear Opening Diameter:
20.5"
Frame Flange Diameter:
36"
Frame Opening Diameter:
24.5"
Grate Diameter:
22.5"
Bolted:
Bolted
|
